The RAM Cards Are Gone – Why You Should Buy A Midi Interface

Midi Tips 5 Comments »

Hardly a week goes by where I don’t get at least a couple of e-mails from someone looking to buy our sounds on the old RAM cards. I usually respond and explain that the cards have not been made in many years and are no longer available. I also mention that all our sounds are available in other formats including system exclusive (sysex) or standard midi files and that all you need to load them into their synth is a “midi interface”.

I also provide some details has to how it all works and mention that we provide a software app that lets you load in the sounds when you place your order. Included are some links with instructions for both Mac and PC users. I even send along a cool little picture which shows you exactly how to connect everything.

After I send off the response, I sometimes will get a reply from someone asking for more info and interested in getting a midi interface and diving into the world of midi, but more often then not that will be the last I hear from them. For most that do not reply, I can only assume that the words “midi interface” just sounds way too complicated and they don’t want to get into all that “computer stuff”.

I do understand this. Some folks just want to keep it simple. Just insert the RAM card into the keyboard and your ready to roll. Others just don’t want to use their computers for anything but sending e-mail and surfing the web. However, there are a lot of good reasons why every musician with a synthesizer should have a midi interface. Here are a few…..

1- As I mentioned before, the RAM cards have not been made in many years. For some of the older instruments like the Yamaha DX7, Korg M1 or Roland MKS80, the cards have not been made in over 20 years! That’s not to say that they don’t exist anymore. You can probably find someone selling them on ebay if you look hard enough, but there are a few important things that you should know about before you buy one.

All of those old RAM cards have a battery inside of them. It’s usually a small “lithium” battery about the size of a US nickel. The battery usually has a lifespan of about five to ten years. After that, they go dead and whatever data you have stored on the card is lost.

On “some” RAM cards, like the Korg or Roland 256K RAM cards you can actually easily pop out the battery and replace them with a new battery. You can still even get these batteries at places like Radio Shack for a few bucks. HOWEVER, on many other type of RAM cards – like the Roland M64c or M16c or anything for the DX7, the cards are “sealed shut” and unless your highly skilled at opening and resealing the card, once the battery goes dead on those type of cards, that’s it. In other words, if you wind up buying one of these cards on ebay, there is a good chance that it will arrive with a dead battery (since the card is 20 years old or older) and you will have thrown your money away!

Even if your lucky enough to find some of the Korg or Roland 256k cards with the replaceable battery slot, there are other things that can go wrong with the card (like the pins that connect the card to the synth are shot) and even after installing a new battery the card will still not work. What do you expect after 20 years? This is 1980’s technology we are talking about!

2- A midi interface is not as complicated as you think. As you can see in the picture, It’s just a little USB device that you connect to your computers USB port. You then run a midi cable from the midi interface “midi output” to your synths “midi input”. Takes about two minutes to set up everything. There are two types of midi interfaces. One is a actual piece of hardware consisting of a small box or rack mount device that has midi inputs and outputs. You only need a simple one that has one midi in and out. However, if you have a lot of synths and samplers and plan on recording them using midi, you can purchase a larger midi interface which can have up to sixteen in’s and outs. The second kind of interface is just a simple USB to Midi cable. This should also do the job for simple sysex dumps, but I have not had the opportunity to test this yet so it’s possible you may run into problems with certain midi devices if you go this route. A USB to mid cable can be purchased for under $20. Midi interfaces are a bit more, but you can find a simple one that will do the job for around $75. USD. That’s about the same amount of money that you would spend on one or two RAM cards!

As I mentioned, we provide you will a software app with your order that lets you load in the sounds from the computer to your synth. The apps are available for both the Mac or PC users. We also provide instructions on how to set up everything to get your computer and your synth talking to each other. This does take a bit more time to sort out everything, but most users have things set up within an half hour or less. The set up is a bit different depending on which synth or computer you have, but most synths are pretty easy to deal with – the older ones only have a few midi parameters so it’s easy to access the midi section and see what’s going on inside.

If you do wind up having a problem once you get our sounds, we don’t forget about you. I’m happy to answer as many e-mails or phone calls as it takes to get you up and running. Our customer support is as good as it gets.

3- Once you have your midi interface up and running you will now be able to do lots of cool stuff with your computer. Not only can you now load our sounds into your synth, but you can also use the software that we give you to “save” whatever sounds you have in your synths memory to your computers hard drive. The midi interface and software app will work with just about any synth that has midi, so you can now do a “bulk dump” to load and save sounds from any synth you happen to have in your rig that has a midi port.

After you get used to using our app to load and save sounds you can then take the next step and get yourself a “librarian” or “editor”. A librarian is a software app which lets you take several banks of sounds and choose the ones you like most to create your own “custom sound banks”. Need a bank of sounds with just organ or piano sounds? No problem. Just use your librarian to drag and drop all your keyboard sounds into one custom sound bank. Some librarians are sold by music software companies, but there are also lot’s of free ones that can you can download online. An “editor” not only lets you set up your own custom sound banks, but you can also access all your synths parameters and “edit” them to create your own sounds. This is what we use when we create the sounds that we offer for sale. Who knows, maybe you can become the next Patch King! Just like librarians, editors can be purchased or found online for free. The ones that are for sale usually have lot’s more features. Some of them, like Mark Of The Unicorns “Unisyn” or Sound Quests “Midi Quest” are both librarians and editors and work with hundreds of different synths and are the top choice among musicians who want to store and edit sounds with their computers.

Unlike the old RAM cards which will just hold a small number of sounds, your midi interface lets you store all your sounds on your computers hard drive – so you can now store an unlimited number of sounds on your drive and access them with a few click of the mouse. You also don’t have to worry that the battery is going to go dead (like on the RAM cards) and you will lose all your sounds. Also remember that your synthesizer has an internal battery with a lifespan about the same amount of time (5-10 years) as the RAM cards. When your synths internal battery goes dead, just like the cards, you lose all the sounds in the synths memory. When this happens, all you have to do is replace the battery and reload the sounds again using our software app and your back in business!

There are many other good reasons for purchasing a midi interface that I won’t go into at the moment. Your welcome to call or e-mail us if you need any more info and I’ll be happy to fill you in.

Well that’s a mouthful! I hope I’ve convinced you that all this midi stuff is not all that complicated and that you won’t be sorry once you’ve purchased a midi interface. When you get going you will never want to look and another RAM card again!

Click Here To Get To Our Main Catalog Page

Deconstructing Sgt Pepper

Classic Rock No Comments »

This has always been one of my favorite Beatles tunes, so it was a real treat for me when one of my Facebook friends posted the link. As a recording engineer and Beatles fanatic, I wondered exactly how this was done. My best guess was that someone got hold of the master tapes and was able to isolate the four tracks. I didn’t think it could be done with software ripping apart the stereo mix. It sounded too good. And that ending – It blew my mind! No way you can do that with software. I’ve been listening to the track for 43 years and never heard that ending before. What a great find.

I also thought about how The Beatles catalog has always been guarded by tons of lawyers and if someone did indeed use the master tapes without getting any authorization then I wondered how YouTube would allow this to be posted. Something just did not seem right. I asked a couple of my friends about it and they were like, “Oh Yeah, when they did the remixes for The Cirque De Soleil shows, they actually made everything into Pro Tools Sessions and one thing led to another”. I was like “ohhhhhh right”. Sometimes I’m a little slow.

Anyway, I guess it’s OK with the powers that be that this is allowed to stay online. I’m sure glad it is. To be able to see how George Martin and the boys set up the tracks is a real treat. It’s also a great learning tool. Amazing how they were able to create this landmark recording with only two four track machines. It just proves what you can do with limited resources if you know what your doing. Of course, at the time it was all state of the art. We’ve come a long way in 43 years!

Arturia V Synth Bundle Pack

New Kid Nepro Releases 1 Comment »

The best sounds for Arturia’s V synths are now available at the best price around!
Pick up our Special Bundle Pack and save some cash! Get all five of our Arturia V collections for only $100. That’s right! Get our Jupiter 8V, Minimoog-V, Prophet V, ARP2600-V & Moog Modular-V sound libraries for only pennies per patch! 500 new sounds for only $100.
Check out the details and some cool MP3 demos at:

Kid Nepro Arturia Moog Modular V Collection Now Available!

New Kid Nepro Releases No Comments »

The Patch King continues doing what he does best – make patches! Now releasing a cool mix of 100 new virtual analog patches for the Arturia Moog Modular V. The original Moog Modular system was the instrument that originated the term “patches”- referring to the patch cord used to “patch” one module to the next. The sound created was called a “patch”.

Our third release for Arturia’s V Synths following our Minimoog V and ARP2600 V sound libraries includes the usual quality analog mix of synth basses, leads, pads, synth sounds and amazing rhythms using the Moog Sequencer. All done with attention to detail including many modulation and aftertouch effects. All thrill and no fill!

More sounds will be coming soon for the rest of of Arturia’s V Collection including the CS80-V, Prophet-V and Jupiter-8V. Get on our mailing list and stay updated on all the latest releases.

Special Bundle Pack! Get all three of our Arturia V collections for only $60. That’s right! Get our Minimoog, ARP2600 & Moog Modular sound libraries for only pennies per patch! 300 new sounds for only $60.

More info and MP3 demos at The Arturia Section Of Our Web Site!!!

Korg Triton Series Disk Loading Info – How To Move Soundbanks

Midi Tips 2 Comments »

Korg Triton Mix

Directions are for a Triton Classic. There may be minor differences if you own a different Triton model. This tutorial will work with the Triton Classic, Triton Rack, Triton Studio, Triton LE or Triton Extreme. Don’t forget to save your the sounds that are in your Triton before loading in our sounds.

Before attempting to load in any sounds, make sure that the effects are not turned off on your Triton. To check this go to “Global”. There is a section on the lower left side of the screen titled “Effect Global”. There are three parts to it. 1-IFX 1-5 OFF  2-MFX1 OFF  3-MFX2 OFF – Make sure none of them are checked.

All our Korg Triton sounds are set up to load into your “A” bank. If you would like to load the sounds into your A bank, just go to disk mode, choose the PCG file, “choose load” and then “load selected”. Everything will load into your A bank at once. The is the quickest way to load in our sounds.

If you would like to load the sounds into another sound bank, (Banks B, C, D or E) follow these instructions.

PART 1

1-Insert floppy disk into your Triton – Select Disk

2-Select Load

3-Choose the file you want to load and highlight it

4-Select Open

5-Choose Program and highlight it

6-Select Open

7-Select Load/Load selected – in right corner of screen

8-Change from bank A to B, C, D or E – Choose OK – File will load

Repeat  the process and choose “Combis” instead of Programs. You can only load programs into Bank-E.

You do not have to load the Drum Kits & ARP patterns unless you have overwritten the factory Drum Kits or ARP patterns with your own custom kits or patterns.

9- Go to Global/Basic/Change All Bank References

10- Highlight Combination Box

11- Change Program A>A to A>B, C, D, or E Depending on what bank your moving the sounds to

12- Choose OK – Global setting will write to memory

At this point all data should now be moved to the new bank that you have selected. Choose the new bank and play a few of the programs and combos to check and see if everything looks/sounds right.

PART 2

Take note that whatever you have in your “A bank” is now, not going to sound correct in combi mode. That’s because you changed the “Bank References”. What you need to do now is to reload whatever you had in Bank A before you loaded in our sounds and then follow similar steps to change the Bank References back in bank A.

1- Go to Global/Basic/Change All Bank References

2- Highlight Combination Box

3-Change Program  A>B, C, D, or E Depending on what bank you moved our sounds, back to A>A

4- Choose OK – Global setting will write to memory

If you have done everything right then your A Bank should now sound just like it did before you loaded in our sounds and our sounds should now be in one of your other banks.

If you have purchased more then one of our Triton sound collections (we have twelve PCG’s for sale), then you can repeat the process with any of our other PCG collections, each time loading the sounds into a different bank. You can load “up to five” of our PCG’s in the Triton’s memory at the same time. Just keep in mind you can only load programs into Bank E. Combi data can not be loaded into Bank E.

Remember to repeat PART 2 after you have loaded your last set of sounds.

Once you have everything loaded you can then “Save All” in your disk section and then save everything as one PCG file. It takes a little while to set all this up, but well worth it, since you wind up with one file that will load in everything up to five banks at once. You can now create several custom set ups for your live gig or studio session that can load in hundreds of new sounds in just a few seconds.

Click Here For More info and audio demos for all our Triton Sounds

Loading Sounds Into Roland Super JV & XP Series Synths Via Midi

Midi Tips 1 Comment »

Have an old Roland Super JV or XP synth that you want to load new sounds into? Here’s how to set up your synth to receive the sounds.

The following instructions are for the Roland JV1010, JV1080, JV2080, XP30, XP50, XP60 & XP80.

There are two sections in your synth that you need to make adjustments – SYSTEM & UTILITY

SYSTEM SETTINGS

1- Choose system button

2- On Patch Midi Page – Set Receive Ch to #1

3- Use the Arrow Down Button to get to the next page

4- On Sys Exclusive Midi Page – Set RX EXC to “ON”

5- Use Arrow Down Button to get to the next page

6- On Receive Midi Page – Set everything to “ON”

UTILITY SETTINGS

1- Choose utility button

2- On Menu 1 – PROTECT – Use right arrow – scroll to Protect – choose “ENTER BUTTON”

3- On Write Protect Page – Set Internal “Off” & Exclusive “Off”

That should set up your synth to receive the sounds. Look for the midi light to flash when your loading in the sounds from the computer. They end up in your “USER” Bank.

Remember that on Roland synths Midi Channel 1 = Midi Channel 17 – so If you get an error message after setting up the JV or XP, try changing the midi channel in the software your using to load the sounds from channel #1 to channel #17.

If you continue to have problems, there are also a couple of settings in your software that you might need to change – the “buffer” & “transmission speed”. Raise the buffer & lower the transmission speed. Experiment to find the right settings for your system.

More info on all our Roland JV & XP Series sounds can be found “At the Roland Sound Section Of Our Web Site”

How To Load Sounds on Macintosh

How To Load Sounds On PC

Brooklyn Bridge Tribute

New Kid Nepro Releases No Comments »

Yo Brooklyn, this ones for you! My homage to the Brooklyn Bridge.

All music programmed & performed on the Korg M3 using Kid Nepro Soundtrack Mix & Killer Keyboards sound collections.

Arturia ARP2600 V Sound Collection Now Available

New Kid Nepro Releases No Comments »

The Patch King has just released our second soundbank for Arturia’s V Collection. The ARP2600 V sound collection complements our Minimoog V sounds that were released in May. Lot’s of cool analog stuff!

The Kid Nepro Arturia ARP2600 V Collection contains a mix of 100 new virtual analog patches ranging from fat basses to screaming leads, killer pads, cool sound effects and lot’s of great rhythms created with the ARP Model 1601 Sequencer. The collection of new sounds is done with expert care from someone who knows the classic synth very well – so you can be sure that the patches are all well crafted and sound great.

Several other high quality sound libraries for Arturia synths will follow including new sounds for the Moog Modular V, CS-80V, Prophet-V & Jupiter-8V – so stay tuned!

Click Here For More Info & Sound Demos

Loading Sounds Into The Yamaha DX7 Series Via Midi

Midi Tips 7 Comments »

The Yamaha DX7 was one of the best selling synthesizers in the history of electronic music. It’s been over twenty years since the last ones finally rolled off Yamaha’s assembly line, but there are still a lot of them in use all over the world and lots of musicians still looking for new sounds. The sound collection that we programmed for the DX back in the 80’s has been one of our best selling patch sets with over 1000 new sounds in all. The sounds are no longer available on ROM or RAM cards. They come in a system exclusive (also known as sysex) or a standard midi file format (.mid) – so you need to load the sounds using your computer and a midi interface.

Here are some tips on how that is done……

The first thing to remember is that there were several different models of DX7’s. The original “brown” DX was one of the first instruments to have MIDI. It had limited midi features and several bugs which were improved on the later DX7-2 models. The DX7-2 Series included the DX7-2, DX7s and the DX7-2FD. The 2FD had a built in floppy disk drive and we actually offer our DX7 sounds in that format as well. In addition the company “Grey Matter” produced the “E” update. When the E board was installed in the DX it expanded the memory. Loading new sounds into each version via midi is a bit different on each model – so we have listed the set up procedure for each model DX.

In order to load sounds into any of the DX models via midi your need a “Midi Interface” and two “Midi Cables”. There are two types of midi interfaces. One is a actual piece of hardware consisting of a small box or rack mount device that has midi inputs and outputs. You only need a simple one that has one midi in and out. However, if you have a lot of synths and samplers and plan on recording them using midi, you can purchase a larger midi interface which can have up to sixteen in’s and outs. The second kind of interface is just a simple USB to Midi cable. This should also do the job for simple sysex dumps, but I have not had the opportunity to test this yet so it’s possible you may run into problems with certain midi devices if you go this route.

The interface gets connected to your computers USB port. You then run a midi cable from the “Midi out” on your interface to the DX “midi in” port. You can then connect another midi cable from your interface “midi in” to your DX “midi out”. This is called “handshaking” and assures better communication between the DX and your interface. It’s not always necessary to handshake the midi cables, but best to have a second cable around just in case you have to. Some synths will not respond to the dump if the second cable is not connected.

Original DX7
NOTE: You can only load 32 sounds at a time into the original DX7
Select Memory Select
Set Memory Protect Internal to “off”
The original DX will only receive on midi channel 1 – so make sure your software is set to transmit on channel 1
When the display reads “Sys Info Avail”, the DX is ready to receive the data.

Original DX7 NOTE: You can only load 32 sounds at a time into the original DX7Select Memory SelectSet Memory Protect Internal to “off”The original DX will only receive on midi channel 1 – so make sure your software is set to transmit on channel 1When the display reads “Sys Info Avail”, the DX is ready to receive the data.

Grey Matter E Card

If you have the Grey Matter E board installed there are several additional steps: Press “function”, then “operator select” twice to select the “memory” page, push button 31 twice (Memory Protect Internal) and then “off”. This disables the memory protect. Then press “function”, then “operator select” four times to select the “keyboard control” page, push button 2 (Midi in filters: SYSEX) and then “on”. This enables SYSEX data transfer.

DX7-2 Series

In the DX7-2 synths, most of the midi functions and parameters are adjusted using buttons 31 and 32. Make sure you set the “Rcv Ch” on the DX and your software program set to channel 1. The DX-2 series can hold 64 patches in it’s memory. There are two different memory banks (A and B). The “receive block” (button 31) lets you set which memory bank you load the sounds into. You also need to turn memory protection off (Button #14) and set “MIDI IN” to “normal” (button #29). If you don’t do this step, you get no error message and no hint of what is wrong, but the keyboard will not accept the sysex data.

Well that about covers it. If you need a program to load in the sounds we provide a couple of good ones that are easy to use for both the Mac and PC. More info on how to load the sounds using sysex software programs can be found at:

How To Load Sounds on Macintosh

How To Load Sounds On PC

Click Here for more info on our Yamaha DX7 sound collection

Now Available! New Sounds For Arturia V Collection From The Patch King

New Kid Nepro Releases No Comments »

That’s right! The Patch King is now hard at work creating an amazing new library for ALL of Arturia’s V Collection. The Minimoog V is the first release from the new collection and is now available. Several other libraries will follow throughout the year including new sounds for the Arturia Moog Modular V, ARP2600 V, CS-80V, Prophet-V and Jupiter-8V.

The Kid Nepro Arturia Minimoog V Collection contains A cool mix of 100 new virtual analog patches ranging from phat basses to screaming leads, smooth pads, funky effects and a lot more. For us, programming a Minimoog is like riding a bicycle – you never forget how to do it! The collection of new sounds is done with expert care from someone who knows the classic synth very well – so you can be sure that the patches are all well crafted and sound great.

Click HERE For More Info

Sign our guest list and we will contact you as soon as our other Arturia V sounds are available. Please contact us if you need any more info.
